Galvanized iron wire can be classified into hot-dipped galvanized iron wire and electro galvanized iron wire according to the differences of processing and zinc coating.
Material: low carbon steel, Q195 ,Q235 Wire Packing: 25/50kg/coil; 5-10kg/coil; 0.4-1.0kg/coils, 10coils/bundle; plastic film inside and hessian/woven bag outside or according to the customers' requirement.
Technical Data:
Tensile strength: 350-420kg/m2
Zinc coating:10-25g/m2
Diameter: #8 to #22(0.7mm to 4mm)
Feature: Strong breaking strength, softness, hard to rust.
Application: Mainly used in construction as binding wire, express way fencing as fencing wire, binding of flowers as wire ties Process: Processing with high quality low carbon steel wire, through drawing and then annealed or galvanizing.
Package:
Coils in 0.1kgs-1000kgs are available
Inside by PVC strips,outside by white weave bag
Inside by PVC strips,outside by gunny
Small coil in carton then pallet,in spools then carton
Special packages are available upon request.
Gauge | SWG(mm) | BWG(mm) | GB(mm) |
8 | 4.06 | 4.19 | 4.00 |
9 | 3.66 | 3.76 | - |
10 | 3.25 | 3.40 | 3.05 |
11 | 2.95 | 3.05 | 3.00 |
12 | 2.64 | 2.77 | 2.80 |
13 | 2.34 | 2.41 | 2.50 |
14 | 2.02 | 2.11 | - |
15 | 1.83 | 1.83 | 1.80 |
16 | 1.63 | 1.65 | 1.65 |
17 | 1.42 | 1.47 | 1.40 |
18 | 1.22 | 1.25 | 1.20 |
19 | 1.02 | 1.07 | 1.00 |
20 | 0.91 | 0.89 | 0.90 |
21 | 0.81 | 0.813 | 0.80 |
22 | 0.71 | 0.711 | 0.70 |
BWG23-36 can also be produced | |||
Galvanized iron wire can be classified into hot-dipped galvanized iron wire and electro galvanized iron wire according to the differences of processing and zinc coating.
Material: low carbon steel, Q195 ,Q235 Wire Packing: 25/50kg/coil; 5-10kg/coil; 0.4-1.0kg/coils, 10coils/bundle; plastic film inside and hessian/woven bag outside or according to the customers' requirement.
Technical Data:
Tensile strength: 350-420kg/m2
Zinc coating:10-25g/m2
Diameter: #8 to #22(0.7mm to 4mm)
Feature: Strong breaking strength, softness, hard to rust.
Application: Mainly used in construction as binding wire, express way fencing as fencing wire, binding of flowers as wire ties Process: Processing with high quality low carbon steel wire, through drawing and then annealed or galvanizing.
Package:
Coils in 0.1kgs-1000kgs are available
Inside by PVC strips,outside by white weave bag
Inside by PVC strips,outside by gunny
Small coil in carton then pallet,in spools then carton
Special packages are available upon request.
Gauge | SWG(mm) | BWG(mm) | GB(mm) |
8 | 4.06 | 4.19 | 4.00 |
9 | 3.66 | 3.76 | - |
10 | 3.25 | 3.40 | 3.05 |
11 | 2.95 | 3.05 | 3.00 |
12 | 2.64 | 2.77 | 2.80 |
13 | 2.34 | 2.41 | 2.50 |
14 | 2.02 | 2.11 | - |
15 | 1.83 | 1.83 | 1.80 |
16 | 1.63 | 1.65 | 1.65 |
17 | 1.42 | 1.47 | 1.40 |
18 | 1.22 | 1.25 | 1.20 |
19 | 1.02 | 1.07 | 1.00 |
20 | 0.91 | 0.89 | 0.90 |
21 | 0.81 | 0.813 | 0.80 |
22 | 0.71 | 0.711 | 0.70 |
BWG23-36 can also be produced | |||
